Product Summary
The BGY588N is a 550 MHz, 34.5 dB gain push-pull amplifier. It is suitable for CATV systems in the 40 to 550 MHz frequency range and intended for use as a line-extender. Its package is SOT115J.
Parametrics
BGY588N absolute maximum ratings: (1)SL, slope cable equivalent: 0.5 to 1.5 dB, 1dB typ when f = 40 to 550 MHz; (2)FL, flatness of frequency response: ±0.3 dB max when f = 40 to 550 MHz; (3)CTB, composite triple beat: -57 dB max when 77 channels flat; Vo = 44 dBmV; measured at 547.25 MHz; (4)Xmod, cross modulation: -59 dB max when 77 channels flat; Vo = 44 dBmV; measured at 55.25 MHz; (5)CSO, composite second order distortion: -62 dB max when 77 channels flat; Vo = 44 dBmV; measured at 548.5 MHz.
Features
BGY588N features: (1)Excellent linearity; (2)Extremely low noise; (3)Silicon nitride passivation; (4)Rugged construction; (5)TiPtAu metallized crystals ensure optimal reliability.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BGY588N |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BGY588N,112 |
NXP Semiconductors |
RF Amplifier CATV P/P AMP 34.5dB |
Data Sheet |
|
|
||||||||||||
